NEXSCIEN HI-3600L Eyelet Machine (2006)

Brand: NEXSCIEN
Model: HI-3600L
Year: 2006
Serial #: 21-06-080
Type: Eyelet Machine
Voltage: AC220V 50/60Hz
Origin: Korea

Machine specifications:

BEC (Board Error Correction)
Method: LASER beam detect
Accuracy: 0.015 mm

Bowl Feeding System
Used bowl feeding system for optimization of eyelet pin loading
Work Board Holder (W.B.H.)
PCB LOading Speed: 4~5sec
Work Board Holder: Table internal and sensor for correcty PCB loading is installed

Board Handing System (Load & Unload)
Control Method: PLC
System: Vacuum to Magazine (User Selectable). Bridge so included in eyelet base machine (base Standard)
PCB Size: Min. 100mm x 80mm; Max. 330mm x 250mm
PCB Flow: Left --> Right; Right --> Left (User Select)
Magazine Loading: Upper --> 2; Bottom --> 3 (user Select)
Color: PANTONE-1C (User Select). Included eyelet base m/c
