TK1309 - ASM/Siemens Siplace SX2 Placement Machine (2015)

ASM Siemens Siplace SX2 Placement Machine (2015)

Flexible mounting configuration

Machine Type SXV2
- Serial number: M450G-12041460
- Hours of use: 61,476
- Component count: 42731734
- SIPLACE Software Version: 709.1SP3
- SIPLACE Vision Software: 512.2.4
- CPP Head (Part Number: 03053528-05)
      + SN: KL-F1-0007
      + Mfg: 2015
- Twin Head - 1 (Part Number: 03097485-01)
      + SN: KL-F4-0039
      + Mfg: 2015
- Twin Head - 2 (Part Number: 03097485-01)
      + SN: KL-F4-0043
      + Mfg: 2015
- Stationary Camera SST33 (Part Number: 03016339-07)
      + SN: KL-F1-0011
- Single-lane conveyor
- Feeder capacity: 120 x 8mm slots
- Component spectrum: 0201(metric) to 200 mm x 110 mm x 50 mm
- Board size: 50 mm x 50 mm to 560 mm x 560 mm
- Machine dimensions (L x W x H): 1.5mm x 2.8m x 1.8m
- Placement accuracy: 22 μm @ 3 σ (with Placement Head TH)

NOZZLES Currently in the machine:

+ Nozzles for CPP Head
- Nozzle - #2817 3x pcs
- Nozzle - #2820 2x pcs
- Nozzle - #2035 6x pcs
- Nozzle - #2007 3x pcs
- Nozzle - #2006 12x pcs
- Nozzle - #2004 12x pcs
- Nozzle - #2003 11x pcs

+ Nozzles for Twin Head
- Nozzle - #517 2x pcs
- Nozzle - #518 2x pcs

CPK VALUE

+ CPP:
- X value: 3.32
-Y value: 2.61
+ Twin Heads ;
- X value: 2.44
- Y value: 3.03
